Lynch Now Offering HPUA & T Control Option from Sun Hydraulics

We are excited to announce the launch of Sun Hydraulics HPUA Hand Pump and the Sun Common (SC) cavity cartridge valves. These new SC cavity cartridges are optimized for lower-pressure systems. These valves boast a common SAE style cavity, which is compliant to SAE cavity standard ISO 17209:2013.

The HPUA Hand Pump

The HPUA is designed to provide hydraulic power to operate valves, cylinders, motors, and other hydraulic components in a wide range of industrial equipment. This valve is a screw-in, manual hand pump cartridge with dual integrated check valves.

It is manufactured to fit perfectly into the Sun Common SC-10-02 cavity, offering the following features:

Cavity SC-10-02
Series 1C
Capacity .442 in³
Maximum Operating Pressure 3000 psi
Valve Hex Size 7/8 in.
Valve Installation Torque 45 – 50 lbf ft
Seal kit – Cartridge Buna: 99C102007
Seal kit – Cartridge Viton: 99C102006

For more information:

HPUA >

Lynch is carrying the new T-control kit option for FNUC & DNUC.

The FNUC – T

FNUC-T is a 4-way, 3-position, electro-proportional, solenoid-operated directional valve with a pressure capacity of 3600 psi (250 bar) and is Sun Common Cavity.

This valve is direct actuated and requires no minimum hydraulic pressure for operation. Features include:

Cavity SC-10-04
Series 1C
Capacity 10 gpm
Maximum Operating Pressure 3600 psi
Typical Valve Leakage at 110 SUS (24cSt) 110 mL/min.@3600 psi
Response Time – Typical 50 ms
Solenoid Tube Diameter .75 in.
Valve Hex Size 1.00 in.
Coil Nut Torque 3.5 – 3.9 lbf ft
Valve Installation Torque 28 – 32 lbf ft
Mounting Bolt Installation Torque (T Control) 4.2 – 4.6 lbf ft
Model Weight (with coil) 1.20 lb
Model Weight 1.58 lb.

For more information:

FNUC – T >

THE DNUC – T

The DNUC-T is a direct-acting, solenoid-operated, 4-way, 3-position spool valve. This valve is direct actuated and requires no minimum hydraulic pressure for operation.

The DNUC-T comes with the following features:

Cavity SC-10-04
Series 1C
Capacity 7 gpm
Maximum Operating Pressure 3600 psi
Typical Valve Leakage at 110 SUS (24cSt) 11 in³/min.@3600 psi
Response Time – Typical 50 ms
Switching Frequency 15,000 max. cycles/hr
Solenoid Tube Diameter .75 in.
Valve Hex Size 27 mm
Coil Nut Torque 3.5 – 3.9 lbf ft
Valve Installation Torque 28 – 32 lbf ft

For more information:

dnuc – t >

991-291- Momentary bi-directional, hand-actuated control kit, T Control

The 991-291 Momentary bi-directional, hand-actuated control kit, T Control, allows the operator to temporarily shift the valve by rotating the lever in either direction.

It is to be used in conjunction with the FNUC-T and the DNUC-T.

Material Zinc Plated Steel
Description Momentary Bi-directional Operation (T Control Option)
Mounting Bolt Installation Torque (T Control) 4.2 – 4.6 lbf ft
Model Weight 0.80 lb.

For more information:

992 – 291 >

We are excited to offer these products to our customers. Whether you are looking for a reliable hand pump or a highly efficient control kit, we have you covered.

If you’re interested in learning more information, reach out to a member of our Sales Team today by emailing sales@lynch.ca, or calling us toll-free at 1-888-626-4365.

ARTEMIS I and the future of Space Travel

*Detailed Artemis I Flight Map. Credit: NASA*

Artemis I was a significant mission for NASA, as it marked their return to lunar exploration after decades of absence. As the first in a series of increasingly complex missions that will enable human exploration of the moon and eventually mars, the main objectives of the Artemis Program is to test and validate Exploration Ground Systems (EGS), Space Launch System (SLS) and the Orion Capsule System.

The mission is the first integrated flight test of NASA’S deep space exploration system. Artemis I involved the unmanned launch of the Orion spacecraft on the Space Launch System rocket from the Kennedy Space Center on November 16, 2022. After completing one flyby of the Moon on November 21 and a second on November 25, the Orion spacecraft returned to Earth, successfully splashing down safely in the Pacific Ocean on December 11.

After its 1.4-million-mile mission around the moon and back to earth, the capsule was transported from San Diego, California to Kennedy’s Multi Payload Processing Facility in Cape Canaveral, Florida, by truck, arriving December 30^th, 2022.

With Orion safely back at Kennedy, technicians have begun removing payloads from the capsule, for inspection, analysis and de-servicing operations. (See updates and photos from NASA)

The successful completion of Artemis I paves the way for a series of crewed future missions, including Artemis II, a crewed lunar fly-by that is presently scheduled for 2024.

Did you know that hydraulics not only work in space, but they play an essential role in the operation of space vehicles, their logistics and infrastructure? Properly functioning hydraulics on space vehicles are critical to ensuring missions are safe, efficient, and successful. Lynch is proud of its role in Artemis I and looks forward to NASA’s future missions to the moon and beyond!

Ecoline – New Energy efficient Valves from SUN Hydraulics & FASTER Quick Release Couplings (QRC)

BE A PART OF THE SOLUTION

‘Reshaping the cartridge valve industry with sustainable valves’

As the global consequences of climate change and energy control become more evident, there is a greater emphasis on energy conservation in all industries.

Our innovative partner, SUN Hydraulics is doing their part as they introduce the new energy-efficient valves in their new ECOLINE™ program now available at Lynch Fluid Controls.

The Ecoline™ program, is a selection of fuel/energy saving, cost-effective valves that can reduce energy consumption by as much as 70%.
Please take this into consideration while moving forward in your current or very next design. Creating machines and systems that have increased range and reduced operating costs are sure to bring a smile to your customers faces.

In addition to the Ecoline™, Lynch has also added the Quick Release Couplings (QRC) line of products to its catalogue. Products include Faster, Diagnostic and FFH Flat Faced Quick Release couplings. Faster quick-release couplings in hydraulic integrated packages enables customized solutions for a wide range of hydraulic applications

QRC

Lynch Fluid Controls continues to provide new and improved services to our
customers by expanding the catalogue with SUN’s products. Get in touch with us by filling out the contact form on our website or email us at sales@lynch.ca

Hydraulics in Defense and Aerospace

When thinking about hydraulic applications, defense and aerospace are quite often at the top of the list.
Many industries such as mining, construction, forestry, oil and gas, and utilities routinely use hydraulics in the operation of heavy machinery.
What is not common knowledge is that a vast amount of the technology was developed and advanced through necessity by the defense and aerospace sectors.

Hydraulics is a technology involving a mechanical function that operates through force of liquid under pressure. This force greatly surpasses the force created by electronic or pneumatic means.

Power density is the key reason for using hydraulics in military applications, particularly where power and precision are required. Hydraulic systems can provide the high levels of force necessary to operate heavy equipment, as well as the precise control needed for delicate operations.

Examples of Hydraulic Use in Defense Applications (a few, there are many!)

Controlling robotic arms

Hydraulic systems offer several advantages for defense applications, including high power-to-weight ratios, compactness, and reliability. Hydraulic systems are an essential part of defense equipment and have played a vital role in the defense of countries around the world.

From countering powerful recoil to providing precision, hydraulics take the spotlight. Using robot arms in munitions factories help reduce injuries amongst workers and enable fine precision work which would be hard for a person to undertake by hand. The hydraulics in robotic arms allow for a superior level of control and accuracy in movement.

Lifting and positioning aircraft parts during assembly & maintenance

Hydraulics do the heavy lifting during aircraft maintenance, allowing machinery to lift and maneuver parts into the correct place safely. Hydraulics really do provide the backbone of the defense industry, allowing for much quicker and more efficient turn arounds between missions and enhancing the safety of ground crews.

Moving heavy loads around military bases

Many military ground vehicles have hydraulic parts including loading ramps that allow for easy transport of heavy loads around bases and shipped decks. Hydraulics are often used when stability and accuracy are key, for example if munitions are being transported, it is paramount that they are done so in a safe and reliable manner.

Hydraulics you can trust

Lives depend on hydraulic system reliability. At Lynch, we take safety very seriously.
Having a hydraulic system that has been built by experts and rigorously tested is essential.

Our team of Hydraulic Engineers are among the best in the world, with many years of diverse experience. They continue to work with top defense and aerospace companies and adhere to the highest standards in engineered manifold systems.

Lynch offers research and development services. FEA, CFD, Life Cycle Testing, Static & Dynamic Testing, Burst pressures to 100,000 PSI.

Certifications and Standards

ISO9001:2015
AS9100D
Controlled Goods Program (CGP), Defense Logistics Agency (DLA), ITAR, Compliant

For three decades, Lynch Fluid Controls has taken pride in maintaining rigorous quality accreditations to deliver superior products with unsurpassed attention to quality, safety, and reliability.

Best Defense Conference 2022

Lynch Fluid Controls is a leading provider of hydraulic and motion control systems across a wide range of sectors. Visit our friendly and welcoming team at the Best Defense Conference in London, Ontario from November 16 -17, 2022 to learn how we will save you time and resources by being a single-source solution to engineer, manufacture, assemble, test and validate your next hydraulic defense solution.

Enovation Controls and Lynch’s Partnership

Enovation Controls has been a proud supplier of rugged displays, controls and instrumentation to Lynch Fluid Controls since 2018. The partnership, which began when Enovation Controls acquired the High Country Tek product line, has grown to include the entire catalog of reliable Murphy-branded products for engines, engine-driven equipment, and specialty vehicles.

Lynch is a highly capable integrator of Murphy-branded solutions with knowledgeable personnel and more than 34 years of intense application expertise in industries including mining, agriculture, forestry, energy, military, defense, and aerospace. As your partner, Lynch provides the right product and ensures customers receive the quality service and support only an authorized provider can deliver. In partnership with Enovation Controls, Lynch delivers reliable solutions that are the best value for both product and support before and after the sale.

Originally founded in 1939 by Pat Murphy, Enovation Controls operates today as a stand-alone subsidiary of Helios Technologies. It is joined by Sun Hydraulics, Faster S.R.L., and Balboa Water Group in the Helios portfolio of companies. Enovation Controls has been ISO 9001 Certified since 1998 and is a well-respected and trusted partner to major engine and equipment manufacturers around the world, consistently meeting and beating specification standards that are rarely matched.

Murphy products and Enovation Controls developed technologies expertly address critical needs and industry trends, enabling the ability to view and control engine and machine functions and diagnostics, making equipment more efficient and enhancing the operator experience.

Customers in the territory may also be familiar with FW Murphy products designed for Oil & Gas Production and Natural Gas applications. These O&G specific solutions are supplied by FW Murphy Production Controls, which was formerly part of Enovation Controls prior to the Helios acquisition, but is now a separately owned entity with its own distribution network.

Enovation Controls Top Performing Distributor - 2021 Award

Driving for Safety – Lynch’s Integrated Custom Work

The Fluid Power Journal is featuring Lynch Fluid Controls in its December 2020 magazine. This article highlights a safety-hydraulic system with integrated electronics for the off-road suspension industry that was designed, manufactured, and tested by Lynch Fluid Controls. Read the full article here.

Enovation Controls’ New Murphy PowerView Displays

Enovation Controls announces the release of their Murphy PowerView^® 700, a 7-inch edge-to-edge glass display in the Murphy^® PowerView series of high-performance displays. With an IP69K-rated enclosure, glove-friendly capacitive touch screen, and an optically-bonded cover glass for superior sunlight visibility, the PV700 is the ultimate rugged display for tough environments. The button-less modern design makes the PV700 a compact and durable addition to in-cab or exterior applications with the perfect amount of power to deliver increased productivity, efficiency, and control.

Click here to learn more.

A Highlight on Lynch’s Green Initiatives

We take Green Initiatives, Sustainability, and Corporate Social Responsibility seriously here at Lynch and our efforts have caught the attention of a local conservation association in Ontario.

Established in 1954, Credit Valley Conservation (CVC) is one of 36 Conservation Authorities in Ontario with a mandate to ensure Ontario’s water, land, and natural habitats are conserved, restored, and responsibly managed through watershed-based programs.

Check out this article by Credit Valley Conservation on our green initiatives, both big and small, that help to take care of the world we live in.

Lynch highlighted in Drop The Pressure Magazine

Read all about Lynch’s journey through the years from our friends at Fluid Power Net in their newest edition of Drop The Pressure Magazine. “Helping to put on a show. How Lynch has contributed to the entertainment industry, and more.” describes how Lynch has been able to support customers’ hydraulic needs in unique industries, including Entertainment.

Lynch Group of companies has for 33 years been a global leader in the design, manufacturing, and distribution of motion control solutions, and integrated hydraulic/pneumatic sub-systems.
Drop the Pressure Articles, by Tom Wootten

Magnom – Future Proofing of Hydraulic and Lubrication Systems

We must ‘Future Proof’ our design specifications and continue to inject new technology into our systems to improve performance, reliability & availability while reducing warranty & ownership cost.
Magnom News

Have you ever wondered what causes failure of an otherwise healthy fluid system? Turns out the biggest risk for your hydraulic system, aside from heat, is microfine contaminants! These super sharp and incredibly hard particles circulate through hydraulic systems causing degradation of critical components.

Magnom filters have been solving this problem for over 80 years! They have the unsurpassed ability to remove microscopic ferrous particles from fluid systems regardless of where they are within the system. The patented core design ensures there is negligible pressure drop across the filter.
Read the full article here.

Magnetic pre-filtration can increase the lifetime of hydraulic filters up to 40%.
Parker Hannifin’s Statement on Effective Magnetic Filtration

Lynch Fluid Controls is the Official Canadian Distributor for Magnom Filters. To learn more about this revolutionary brand Contact Us!
